A check valve, also known as a non-return, reflux, retention, foot or one-way valve, is designed to allow liquids or gases to flow through a pipeline in only one direction. The valve operates automatically, opening when fluid flows in the correct direction and closing when the flow stops or reverses. This helps prevent backflow, protect pumps and other equipment, maintain system pressure and improve overall process reliability. Check valves are widely used across mining, water treatment, chemical processing, power generation, oil and gas, and general industrial applications.

01: TYPE
Flanged and Butt Weld
02: RANGE
•Size: DN50 up to DN 600mm
• Pressure: ANSI 150 to ANSI 900
• Temperature; -30 °C to 816 °C
03: MATERIAL BODY
• Carbon Steel: ASTM A216 Gr WCB
• A217-WC6 & WC9, A352-LCB
• Stainless Steel: 304 & 304 L - 316 & 316 L

04: TRIM
• 13% Chrome
• 304 SS & 304 L
• 316 SS & 316 L
• 317
• Monel
• Other materials on request
05: VALVE OPERATED
• Hand Lever
• Actuated
06: DATASHEETS
For any specific ball valves datasheet please email us on sales@pacevalves.co.za
