Welcome to

 PACE VALVeS -

Process & Allied Contracting Equipment...

A comprehensive service provider of industrial valves


1D8C4B
1D8C4B

7AB901D0
7AB901D0

IMG-20200525-WA0163
IMG-20200525-WA0163

1D8C4B
1D8C4B

1/23

PRODUCTS

Triple Offset Wafer Type Butterfly.jpg
Butterfly Valves









GENERAL PURPOSE DESIGN

Type

On Centre Disc
Wafer, Lugged & Flanged

Range

• Size; DN40 up to DN 1200mm
• Pressure; 20 Bar maximum
• Temperature; -34 °C to +180 °C


Materials Body

• Cast Iron
• Ductile Iron
• Carbon Steel
• Aluminium
• Aluminium Bronze
• Stainless Steel

Disc

• Ductile Iron Nickel plated
• Stainless Steel
• Aluminium Bronze
• Exotic Alloys

Seat

• EPDM
• NBR
• SBR
• Viton
• Silicone
• Teflon
• Neoprene

Ball Valves







Type

Screwed, Socket, Butt Weld,
Flanged and Wafer
Bar Stock, Two Piece and Three Piece
Multi-Ports, Reduced and Full Bore
Optional: Anti Static, Fire Safe
and Locking Device

Range

• Size; DN6 up to DN 300mm
• Pressure; up to 2000 WOG, ANSI 150 and 300, DIN PN10,
16 & 40
• Temperature; -30 °C to 232 °C


Materials

Body / Trim

• Carbon Steel WCB
304 SS & 316 SS
Alloy 20
Other alloys on request


Seat

• PTFE
RTFE
Peek

Wafer Check Valves
Wafer Check Valve
igh Pressure Knife Gate - Copy - Copy.jp





Type

Wafer Pattern Double Door or Swing Check

Range

• Size; DN50 up to DN 1350mm
• Pressure; ANSI 125 up to ANSI 2500
• Temperature; up to 530 °C maximum

Materials

Body

• Cast Iron
Carbon Steel
Stainless Steel
Bronze
Aluminium

Seat

• Buna "N"
Neoprene
EPDM
Teflon
Viton
Monel
316 SS Overlay
410 SS SS Overlay
Aluminium Bronze
Stellite 6 Overlay

Knife Gate Valves









Type

Ends Wafer, unlined, lugged,
flanged Rubber urethane lined

Range

• Size; DN50 up to DN 1000mm
• Pressure; up to 10 Bar maximum
• Temperature; up to 130 °C

Materials

Body

  • Cast Iron
    Ductile Iron
    304 SS
    316 SS

Trim

  • Nitrile
    EPDM
    Teflon
    Viton



Strainers
Strainers









Type

"Y" Strainers, Duplex and Basket
Screwed, Socket, Butt Weld or Flanged
Perforated, Wire Mesh and Magnetic Screens

Range

• Size; DN6 up to DN 900mm
• Pressure; up to ANSI 2500
• Temperature; up to 600 °C

Materials

Body

  • Cast Iron
    Ductile Iron
    Carbon Steel
    Bronze
    304 SS
    316 SS & 316 L
    Alloy 20
    Monel
    Hastelloy



Control Valves









Type

Pilot Operated, Multi Functional Control
Screwed and Flanged
Functions: Pressure Reducing & Relief, Level Control, Flow Control Solenoid On/Off, Non Return

Range

• Size; DN25 up to DN 300mm
• Pressure; 25 Bar maximum
• Temperature; up to 90 °C

Materials

  • Bronze
    Ductile Iron
    Epoxy Coated, Standard
    Special Coatings Available

Trim

  • Natural Rubber
    EPDM
    Nitrile
    Butyl
    Viton



Gate, Globe and Check Valves





Type

Flanged & Buttweld

Range

• Size; DN50 up to DN 600mm
• Pressure; ANSI 150 to ANSI 900
• Temperature; -30 °C to 816 °C

Materials

Body

• Carbon Steel; ASTM A216 Gr WCB
A217-WC6 & WC9, A352-LCB

• Stainless Steel;
304 & 304 L
316 & 316 L

Trim

• 13% Chrome
• 304 SS & 304 L
• 316 SS & 316 L
• 317
• Monel
• Other materials on request

UPVC Valves
Thermoplastic Valves









Type

Butterfly, Ball, Check and Diaphragm
Single and Multi-Port
Screwed, Spigot, Flanged and Wafer

Range

• Size; DN10 up to DN 300mm
• Pressure; 15 Bar maximum
• Temperature; -20 °C up to 150 °C

Materials

Body

  • PVC, UPVC & CPVC
    PP, PP + GF
    PVDF
    ABS

Seat

  • PTFE (Teflon)
    EPDM
    FPM (Viton)

Safety Relief Valves









Type

Full-Nozzled & Semi-Nozzled
Spring-Loaded Angle Pattern
Screwed & Flanged

Range

• Size; 1" x 2" D' orifice to 8" x 10"
'T' orifice (flanged)
1/2" x 1/2 to 2" x 2" (screwed)
• Pressure; ANSI 150 to 2500 (flanged)
Up to 5000 PSI (screwed)
• Temperature; -268 °C up to + 538 °C maximum

Materials

Body

  • Carbon Steel
    Alloy Steel
    Stainless Steel
    Bronze
    Exotic Alloys

Trim

  • Stainless Steel
    Bronze
    Exotic Alloys



Ropo actuators.jpg

RoPo Pneumatic Actuators



RoPo now offers the largest portfolios of actuation and controls products available in the market today. We have the applications experience and customization capabilities to find the optimum solution for your valve automation needs.

Solenoid Valves



We offer a variety of Solenoid Valves.

Solenoid 3-2 way direct acting.png




1981

Year Established

Level 2

1981/007906/07

Registration No

ABOUT

Through our comprehensive range of products we are able to service a large variety of process applications, and are able to cover most sectors of the valve - user industry, such as:

mining, minerals benefication, chemical, petrochemical, water treatment and distribution, iron & steel production, power generation and pulp & paper.

We are able to service all of the major industrial, mining and commercial sectors in South Africa through direct coverage.

We provide quality fit-for-purpose products backed by consistent and reliable service, for the mutual benefit of our customers, the company and our suppliers.

This philosophy has been strictly adhered to throughout the history of the company and has enabled a track-record within the South African valve-user industry which is second to none.

Each and every customer contact is developed via the pursuit of the following objectives.

- correct interpretation of customer requirements, both from technical and commercial perspectives.

- identification of the most appropriate source of supply, with consideration of specification, price and availability.

- commitment to customer satisfaction, after sales service and support.



CLIENTS



CONTACT

Enquiries

For any enquiries, questions or quotes, please call (+27) (0)11 452 6826 or email: enq@pacevalves.co.za or fill out the following form

Success! Message received.

Head Office

148 10th Avenue

Edenvale

JHB

1609

enq@pacevalves.co.za

Tel: 011-452 6826

Fax: 011-609 4223

Employment

There are currently no vacancies available at PACE Valves.

Get a quote: 011-452 6826
